This page contains our crankset power meters for road bikes. With a crankset power meter, you replace your existing crankset with a new, power equipped crank. While they can cost a bit more than other types of power meters, crankset-based power meters are perhaps the most highly regarded. They are proven, reliable and accurate. Pros often rely on crank-based power meters for a reason!
You can find a crank power meter to fit just about any bike. In addition, you don’t have to make any compromises to your component selection. For example, you don’t have to use different pedals (as with a pedal-based power meter) or a different hub (as with a hub-based power meter).
Additional Crankset Power Meters for Road Info:
Brands
We carry crankset power meters from 4iiii, FSA, power2max, ROTOR, Shimano, SRAM/Quarq, SRM, Stages and Verve.
Options
There are several different crankset road power meters to choose from based on your budget, bike and what features you are interested in (independent left/right power, Bluetooth SMART, etc.). Please note that some of these cranks include chainrings and some do not.
Note on Compatibility – 4iiii and Stages Dual-Sided Cranks
The 4iiii and Stages cranksets attach sensors to the inside of the crank arms. On some bikes, there is not enough room between the left crank arm and the chainstay for the sensor to clear the frame. Therefore, you should make sure you have at least 10 mm of clearance for Stages and 4iiii PRECISION 2 power meters and 8 mm of clearance for 4iiii PRECISION 3 power meters. Also, make sure that you don’t have a bottom bracket mounted rear brake (used on some aero and TT bikes). Please refer to the image below.
Quick Product Comparison:
Price
Prices range from around $400-500 to over $2,000. Please note, some of the lower priced options on the page are just the power meter spider and don’t include cranksets. power2max power meter cranksets offer a great value with several models in the $700-900 range. Right around the $1,000 mark you have options from 4iiii, Shimano, Stages and ROTOR – all very popular, highly-regarded cranksets.
Installation
Crankset-based power meters take more time to install than other power meter types. This is because you must remove your current crankset from your frame and install the new one. Installation typically takes around 30-60 minutes.
Power Measurement
All of these crankset power meters measure power from both legs (with the exception of the ROTOR INpower and 4iiii PRECISION Shimano Ultegra R8100 Single-Sided Crankset, which measure left leg power only). Some units such as the 4iiii, Shimano, Stages, ROTOR and Verve are also able to measure independent left and right leg power. They do this by using two different power sensors on both sides of the crank.
power2max and FSA have the ability to provide estimated left/right power. This is similar to, but not quite as precise, as independent left/right power measurement.
ANT+/Bluetooth SMART
All of these units, with the exception of SRM PM7 and Verve power meters, use dual ANT+ and Bluetooth SMART. The SRM PM7 and Verve power meters are compatible with ANT+ devices only. Please note, SRM PM9 power meters do offer both ANT+ as well as Bluetooth SMART.
Batteries
Some of these crankset power meters use replaceable coin cell batteries while others use rechargeable batteries. The exact battery type for each power meter is listed on the product page, along with the average run time. Coin cell batteries last longer but rechargeable batteries eliminate the need of having buy and replace batteries.
Weight
Crankset power meters add anywhere from 50-250 grams to the weight of the crankset, based on the version.
The most affordable crankset capable of measuring independent left/right power!
4iiii's 3-D tri-axial strain gauge technology, dual-sided power and +/- 1.0% accuracy
4iiii left side power on a Shimano Ultegra 12-speed crankset!
4iiii's left/right power measurement on Shimano's top-end DURA-ACE 9100 cranksetROTOR 2INpower DM Road Power Meter
$879.20 – $960.00State of the art design, direct mount chainrings and dual-sided power!ROTOR INpower DM Road Power Meter
$540.00 – $650.00ROTOR's trusted INpower now with direct mount rings and Bluetooth SMART!power2max NGeco ROTOR ALDHU Road Power Meter Crankset
$690.00 – $860.00One of our best-selling power meter cranksets. Available in ALDHU 24 or 30 MM!power2max NGeco ROTOR ALDHU Carbon Road Power Meter Crankset
$890.00 – $1,010.00One of our best-selling power meters on a ROTOR ALDHU carbon crankset!power2max NGeco ROTOR p2m Edition Road Power Meter Crankset
$590.00 – $610.00The best-selling ROTOR ALDHU crank with more budget friendly p2m Edition crank armspower2max NGeco p2m Gran Fondo Power Meter Crankset
$560.00 – $580.00A budget friendly direct replacement for your Shimano crankset!power2max NG ROTOR ALDHU Road Power Meter Crankset
$1,090.00 – $1,260.00power2max’s premier NG power with ROTOR 24 or 30 MM ALDHU road crankset!power2max NG ROTOR ALDHU Carbon Road Power Meter Crankset
$1,290.00 – $1,410.00power2max’s premier NG power with ROTOR ALDHU carbon crank arms!SRAM RED AXS Power Meter Crankset
$1,158.85 – $1,291.00A SRAM RED AXS crankset with Quarq’s DZero power measurement technology!
Shimano Ultegra R8100-P Dual-Sided Power Meter Crankset
$1,069.99 – $1,159.99Dual-sided power on a Shimano Ultegra R8100 crankset!SRAM RED 1x AXS Power Meter Crankset
$1,158.85 – $1,291.00The perfect 1x power meter for triathletes, time trialists and cyclocross racers!
Left/right power measurement, +/- 1.0% accuracy and dual ANT+|Bluetooth SMART
Shimano DURA-ACE R9200-P Dual-Sided Power Meter Crankset
$1,309.99 – $1,469.99Dual-sided power on a Shimano DURA-ACE R9200 crankset!
Stages dual-sided power with +/- 1.0% accuracy on a Shimano 9100 cranksetpower2max NGeco Easton Road Power Meter Crankset
$690.00 – $960.00One of our lightest, strongest and most powerful power meter cranksets!Quarq DZero DUB Power Meter
$364.65 – $763.65The ultimate spider-based power meter: accurate, durable and consistent!
