SRM PM9 Origin Road Aluminum Power Meter

Niel Ubod May 23, 2024


The NEW SRM Road Origin with affordable aluminum crank arms! Accurate and compatible with almost any bike!


Clear selection

SRM PM9 Origin Road Aluminum Power Meter

The SRM PM9 Origin Road Aluminum Power Meter adds another option for riders that want to take advantage of the best SRM has to offer. With the Origin Aluminum, you get the accuracy, consistency and durability SRM is known for, but at a price below that of the Carbon version. In addition, if you’re looking to run shorter crank arm lengths, the Origin Aluminum has you covered! The Origin also offers near limitless compatibility with exchangeable 24 mm, 30 mm and 29 mm spindles, which means it can be used on virtually any frame on the market.


Key Product Details


This power meter is compatible with 110 BCD 4-bolt chainrings. It fits 24 MM, 30 MM or 29 MM DUB bottom brackets, depending on the version ordered. See Compatibility tab for more information.

Power Measurement:

This SRM power meter measures power at the spider and is therefore able to measure power from both legs.

Key Features:

Dual-leg power measurement, accurate to within +/- 1.0%, lightweight, rechargeable battery, 100 hours of battery life, left/right power balance, automatic temperature compensation, ANT+ and Bluetooth compatible, 2-year warranty. See Specs tab for more information.

Advice From Our Staff:

This power meter has all of the features of the more expensive PM9 Carbon version, but just substitutes the carbon crank arms for more affordable aluminum ones. It is highly accurate, looks amazing and comes with a solid 2-year warranty. You can mount a wide range of both 2x and 1x chainrings to it, from Shimano to Carbon-Ti to ROTOR and more. In addition, with an option to order it with a 24 mm, 30 mm or DUB spindle, you can put it on almost any bike.



Crank Arms:

The SRM Aluminum crank arms are available in the following sizes:

  • 160 mm | 165 mm | 167.5 mm | 170 mm | 172.5 mm | 175 mm


  • 9200 Lid – For Shimano 9200 chainrings
  • 9100 Lid – For Shimano 9100 chainrings
  • Flat Lid – For any other 110×4 chainrings

9200 Lid

9200 Lid

9100 Lid

9100 Lid

Flat Lid

Flat Lid


  • 24 MM – For use with 24 mm Shimano bottom brackets
  • 30 MM – For use with 30 mm bottom brackets
  • 29 MM DUB – For use with DUB bottom brackets

PC8 Bundle:

While not listed in the dropdown menus above, you can bundle the SRM PM7 Origin Power Meter with a SRM PC8 Bike Computer. When you do, you get $249 off the standard price of the PC8. Please contact us if you would like this option.


Chainrings For Your Power Meter

Here are the most commonly ordered chainrings with this power meter. You can simply add them to your cart along with your power meter and we will install them for you.


Chainrings: The SRM PM9 Origin is compatible with any 110 BCD 4-bolt asymmetric chainrings (Shimano, SRM Aluminum, Carbon-Ti, ROTOR, etc.).

Bottom Bracket: This power meter fits 24 MM, 30 MM or 29 MM DUB bottom brackets, depending on the version ordered. If you are ordering the same size as you currently have on your bike, you should be able to re-use your existing bottom bracket. However, if you are chaining spindle sizes, you will need to replace your bottom bracket. Please contact us with questions, we are happy to help.

SRM PM9 Origin Road Aluminum Specs

NameSRM PM9 Origin Road Aluminum
Bike TypeRoad
Location of Power MeasurementSpider
Left or Both Legs MeasuredBoth
Independent Left/Right MeasurementYes - Power Balance
InstallationMore involved (60 min. estimated)
Crank Arm MaterialAluminum
Communication ProtocolANT+ and Bluetooth SMART
Claimed Accuracy+/- 1.0%
Active Temperature CompensationYes
WeightVaries based on configuration
Battery TypeRechargeable
Battery Life100 hours
Method of Cadence MeasurementAccelerometer
BCD110 4-bolt asymmetric
Spindle Size24 mm, 30 mm or DUB 29 mm
Q Factor145.5 mm
Warranty2 years

In the Box

  • SRM PM9 Origin Road Aluminum Power Meter (spider, crank arms and spindle)
  • SRM USB Charger Cable
  • PC8 Bicycle Computer (if purchased)
  • Handlebar mount (if SRM PC8 is purchased)

Tools Needed for Installation

You will need the following tools for installation of this product. You can purchase many of these commonly used tools in our store.

  • 3 mm Allen key
  • 10 mm Allen key

Common Questions and Answers

Question: Can my SRM PM9 power meter store ride data?

  • Yes! The SRM PM9 Power Meter is capable of having rides, torque data, heart rate and core body temperature stored on the circuit board and downloaded to a .fit file. For more information please see our FAQ: Can my SRM PM9 power meter store ride data?

Question: How do I determine what length my current cranks are so I can make sure I get the same size?

  • Your crank arm length should be printed or stamped on the inside of the left crank arm, usually near the pedal end.

End of crank arm showing crank arm length
