Home » SRM Power Meters » SRM PM9 Origin Track Carbon Power Meter
A black and yellow SRM PM9 Origin Track LOOK-SRM Carbon Power Meter against a white background.

SRM PM9 Origin Track Carbon Power Meter

Josh Matthew September 19, 2024

$1,949.00 – $2,349.00

+/- 1.0% accuracy, unmatched consistency and durability plus carbon crank arms
Clear selection

SRM PM9 Origin Track Carbon Power Meter

The SRM PM9 Origin Track Carbon Power Meter is the latest offering in SRM’s new Origin power meter line. In addition to be highly accurate, this PM9 version features Left/Right Power Balance, Magnet-less cadence, Automatic temperature compensation, and Bluetooth SMART, among other new features. You can order it with either LOOK carbon crank arms, which are the lightest, stiffest cranks SRM offers, or SRM Composite cranks. It’s not cheap, but it’s one of the nicest track power meter cranksets you can buy!



Key Product Details

Compatibility:

This power meter is compatible with 144 BCD 5-bolt track chainrings. It fits 24 MM and 30 MM track bottom brackets, depending on the version ordered. See Compatibility tab for more information.

Power Measurement:

This SRM power meter measures power at the spider and is therefore able to measure power from both legs.

Key Features:

Dual-leg power measurement, carbon crank arms, accurate to within +/- 1.0%, lightweight, rechargeable battery, 100 hours of battery life, left/right power balance, automatic temperature compensation, ANT+ and Bluetooth compatible, 2-year warranty. See Specs tab for more information.

Advice From Our Staff:

It’s not cheap, but this is one of the nicest track power meters you can buy. It is accurate, stiff, lightweight, looks great and it comes with a solid 2-year warranty. In addition, with an option to order it with a 24 mm or 30 mm spindle, you can put it on almost any bike.



Options For This Power Meter

Crank Arm:

LOOK-SRM Carbon | SRM Carbon Composite

  • LOOK-SRM Carbon – These are the lightest crank arms offered (260 grams). There are two size options: 165/167.5/170 or 170/172.5/175. The crank arms each function in three lengths simply by rotating the Trilobe pedal inserts.
  • SRM Carbon Composite – These carbon arms are still very light and stiff, but they weigh a bit more than the LOOK-SRM Carbon at 344 grams per set. However, they are also more affordable.

LOOK-SRM Carbon

SRM LOOK Carbon Crank Arms

SRM Carbon Composite

SRM Carbon Composite Crank Arm

Spindle:

24 MM | 30 MM

  • 24 MM – For use with 24 mm track bottom brackets.
  • 30 MM – For use with 30 mm track bottom brackets.

PC8 Bundle:

While not listed in the dropdown menus above, you can bundle the SRM PM9 Origin Power Meter with a SRM PC8 Bike Computer. When you do, you get $249 off the standard price of the PC8. Please contact us if you would like this option.

Compatibility

Chainrings: The SRM Origin Track Carbon Power Meter is compatible with 144 BCD 5-bolt track chainrings.

Bottom Bracket: This power meter fits 24 MM or 30 MM track bottom brackets, depending on the version ordered.

SRM PM9 Origin Track Carbon Power Meter Specs

NameSRM PM9 Origin Track Carbon Fiber
Bike TypeTrack
Location of Power MeasurementSpider
Left or Both Legs MeasuredBoth
Independent Left/Right MeasurementYes - Power Balance
InstallationMore involved (60 min. estimated)
Crank Arm MaterialCarbon
Communication ProtocolANT+ and Bluetooth SMART
Claimed Accuracy+/- 1.0%
Active Temperature CompensationYes
WeightVaries based on configuration
Battery TypeRechargeable
Battery Life100 hours
Method of Cadence MeasurementAccelerometer
BCD144 5-bolt
Spindle Size24 mm or 30 mm
Q Factor145.5 mm
Warranty2 years

In the Box

  • SRM Power Meter (spider, crank arms and spindle)
  • SRM USB Charger Cable
  • PC8 Cycling Computer (if purchased)
  • Handlebar mount (if SRM PC8 is purchased)

Tools Needed for Installation

You will need the following tools for installation of this product. You can purchase many of these commonly used tools in our store.

  • 10 mm Allen key
  • 3 mm Allen key
  • SRM lock ring tool

Common Questions and Answers

Question: Can my SRM PM9 power meter store ride data?

  • Yes! The SRM PM9 Power Meter is capable of having rides, torque data, heart rate and core body temperature stored on the circuit board and downloaded to a .fit file. For more information please see our FAQ: Can my SRM PM9 power meter store ride data?

Question: How do I determine what length my current cranks are so I can make sure I get the same size?

  • Your crank arm length should be printed or stamped on the inside of the left crank arm, usually near the pedal end.

End of crank arm showing crank arm length
